Nuclias Connect AX3000 Access Point

DAP-X3060OU

Wireless Standard	802.11ax Wi-Fi 6
Frequency band mode	2.4G,5G Dual-band simultaneous
Wireless Speed	574 Mbps 2.4GHz 2402 Mbps 5GH
Antenna type	Embedded omni-directional antennas
Antenna gain	5 dBi for 2.4GHz 7.9 dBi for 5GHz
Wired interface	1 x 2.5 Gigabit Ethernet LAN
Indoor/outdoor	Outdoor
Type of housing	Plastic
IP rating	IP68
Wireless modes	Access Point(AP) WDS bridge WDS with AP
Advanced Features	802.11k/r Roaming MU-MIMO
Type	Software Managed AP
Maximum number of SSIDs	16
Management platform	Nuclias Connect
802.1X authentication	Yes
ARP spoofing	Yes
AP traffic load balance	Yes
Auto channel selection	Yes
CLI	Yes
DHCP server	Yes
IGMP Snooping	Yes
IPv6	Yes
L2 roaming	Yes
MAC address filtering	Yes
Power-over-Ethernet	Yes
SNMP(v1, v2c, v3)	Yes
SSID broadcast disable	Yes
Station isolation	Yes
Syslog	Yes
Telnet	Yes
TKIP/AES encryption	Yes
WEB	Yes
WEP 64/128 bit	Yes
Wi-Fi scheduler	Yes
WLAN partition	Yes
WMM-PS/802.11e(U-APSD)	Yes
WPA/WPA2/WPA3-Personal & Enterprise	Yes

No	Description	Title	Type	File Size
1	Datasheet	DAP-X3060OU-EG Datasheet	pdf	0.23 MB
