SPECIFICATION

Hardware Profile

• 1/4” Megapixel progressive CMOS sensor
• 5 meter IR illumination distance
• Minimum illumination: 0 lux with IR LED on
• Built-in Infrared-Cut Removable (ICR) Filter module
• Built-in PIR sensor (5 meter)
• Built-in microphone
• 10x digital zoom
• Focal length: 3.45 mm
• Aperture: F2.0

Field of View

• (H) 57.8°, (V) 37.8°, (D) 66°

Camera Housing

• IP65 compliant weatherproof housing

Image Features

• Configurable image size, quality, frame rate, and bit rate
• Time stamp and text overlays
• Configurable motion detection windows
• Configurable privacy mask zones
• Configurable shutter speed, brightness, saturation,contrast, and sharpness

Video Compression

• H.264/MPEG-4/MJPEG simultaneous format compression
• JPEG for still images

Video Resolution

1. 16:9 - 1280 x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176 up to 30 fps recording1
2. 4:3 - 1024 x 768, 800 x 600, 640 x 480, 480 x 360, 320 x 240 up to 30 fps recording1

Audio Support

• G.726
• G.711

Network Protocols

• IPv6
• IPv4
• TCP/IP
• UDP
• ICMP
• DHCP client
• NTP client (D-Link)
• DNS client
• DDNS client (D-Link)
• SMTP client
• FTP client
• HTTP / HTTPS
• Samba client
• PPPoE
• UPnP port forwarding
• RTP / RTSP/ RTCP
• IP filtering
• QoS
• CoS

Security

• Administrator and user group protection
• Password authentication
• HTTP and RTSP digest encryption

System Requirements for Web Interface

• Browser: Internet Explorer, Mozilla Firefox, or Google Chrome

Event Management

• Motion detection
• Event notification and upload snapshots/video clips via email or FTP
• Supports multiple SMTP and FTP servers
• Multiple event notifications
• Multiple recording methods for easy backup

Remote Management

• Configuration accessible via web browser
• Take snapshots/video clips and save to local hard drive or NAS via web browser

Mobile Support

• Windows 8®/ 7®/Vista®/XP® system, Pocket PC, or mobile phone
• mydlink™ mobile app for iOS and Android mobile devices

D-ViewCam™ System Requirements

• Operating System: Microsoft Windows 8/7/Vista/XP5
• Web Browser: Internet Explorer 7 or higher
• Protocol: Standard TCP/IP

D-ViewCam™ Software Functions

• Remote management/control of up to 32 cameras
• Viewing of up to 32 cameras on one screen
• Supports all management functions in web interface
• Scheduled motion triggered or manual recording options

Power

• 5 V DC, 1.2 A through external power adapter
• External Power Adapter Input:100 to 240 V AC, 50/60 Hz

Max. Power Consumption

• 5.5 watts max.

Operating Temperature

• -13° to 113° F (-25° to 45° C)

Storage Temperature

• -4° to 158° F (-20° to 70° C)

Operating Humidity

• 20% to 80% non-condensing

Storage Humidity

• 5% to 95% non-condensing

Certifications

• FCC Class B
• CE
• CE LV D
• C-Tick

Dimensions

• 2.6” x 5.53” x 3.66” (66mm x 140.5mm x 93mm)

Weight

• 8.99oz (255 grams)
