16-port 10/100/1000Base-T Smart Gigabit Switch

DGS-1100-16 *(This product has been discontinued)




Switch DGS-1100 series is a cost-effective solution for a class of SOHO and small and medium-sized businesses, as well as for networking companies, such as branch offices and meeting rooms that require simple control. Each model comes in a compact desktop metal case and is equipped with 5, 8, 16 or 24 Gigabit ports.

Energy-saving technology D-Link Green
Switches DGS-1100 compliant with IEEE802.3az Energy Efficient Ethernet, while consuming less power with a small amount of traffic. Installation of EEE provides small and medium-sized businesses save money by reducing the costs associated with the purchase of equipment for cooling. Switches DGS-1100 series support the technology D-Link Green, provides automatic reduction of energy consumption. If the automatically determined by the length of cable connected less than 20 meters, the switch reduces power consumption. In addition, the switch determines the connection status of each port and provides automatically powers down ports.

Simple operation
Switches EasySmart support management using SmartConsole Utility or Web-based. SmartConsole easily allows users to detect line switches D-Link Smart in the same network segment L2. Using this tool eliminates the need to change the IP-address and provides easy initial installation series switches Smart. Displayed on the screen switches belonging to the same network segment and connected to the user's local PC, with the possibility of immediate access. Extend the user configuration and basic configuration of discovered devices such as password changes and software updates. Easy to use graphical Web-based interface provides network administrators to remotely manage the network at the port level.

Surveillance VLAN and bandwidth management
Switches DGS-1100 series support the technology Surveillance VLAN for the video. Surveillance VLAN assigns video traffic higher priority and individual VLAN, ensuring high-quality video surveillance and data transmission through one switch DGS-1100, thereby reducing costs associated with the acquisition of additional equipment. In addition, bandwidth management feature allows you to reserve bandwidth for a variety of applications that require high bandwidth, or provide them with the highest priority.

Simple Troubleshooting
The switches support the Loopback Detection and Cable Diagnostics, which allows network administrators to quickly and easily find and fix problems in the network. Loopback Detection is used to detect loops and automatic shut-off port on which a loop was detected. Cable Diagnostics is designed to determine the types of copper cabling, as well as the type of cable error.

Advanced features
Series Switches DGS-1100 supports advanced security features such as Static MAC, protection from the storm and IGMP Snooping. Static MAC function allows you to create a "white list" MAC-addresses, allowing access to only authorized devices.Storm protection function is required to limit to a predetermined threshold, the broadcast, multicast or unknown unicast traffic.Switch blocks or drops packets that are subject to this limitation, since a large number of such traffic can cause network congestion. IGMP Snooping function reduces the number of multicast traffic and increase network performance.
