SPECIFICATION

Hardware profile

• 1/3” 2 Megapixel progressive scan CMOS sensor
• 10 meter IR illumination distance
• Built-in Infrared-Cut Removable (ICR) Filter module
• Minimum illumination:
1.0 lux / F2.0 (color)
0.5 lux / F2.0 (B&W)
0 lux (IR LED on)
• Exposure time: 1/7.5 to 1/10,000 sec.
• Focal length: 2.8 mm
• Aperture: F2.0
• Minimum object distance 300 mm
• 10x digital zoom
• Angle of view: (H) 84°• (V) 46°• (D) 97°
• Adjustment angle (non-motorized)
Pan: 350°• Tilt: 100°• Rotation: 350°
• Built-in microphone and speaker

Camera Housing

• IP-65 compliant weatherproof housing • IK-10 compliant vandalproof housing

Image Features

• Configurable image size, quality, frame rate, and bit rate
• Time stamp and text overlays
• Configurable motion detection windows
• Configurable privacy mask zones
• Configurable shutter speed, brightness, saturation, contrast, and sharpness

Video Compression

• Simultaneous H.264/MJPEG multi-format compression
• JPEG for still images
• H.264 multicast streaming

Video Resolutions

• 16:9 - 1920 x 1080, 1280 x 720, 800 x 448, 640 x 360 up to 30 fps
• 4:3 - 1440 x 1080, 1280 x 960, 1024 x 768, 800 x 592, 640 x 480 up to 30 fps

Audio Compression

• G.711 • AAC

External Device Interface

• 10/100 BASE-TX Fast Ethernet port
• Supports 802.3af PoE Class 2
• microSD/SDHC/SDXC card slot 2

Network Protocols

• IPv6 • IPv4• ARP• TCP/IP• UDP• ICMP• DHCP client• NTP client (D-Link)• DNS client• DDNS client (D-Link)• SMTP client• FTP client• HTTP / HTTPS• Samba client• PPPoE• UPnP• UPnP port forwarding• RTP / RTSP/ RTCP• IP filtering• QoS• CoS• DSCP• Multicast• IGMP• ONVIF compliant• Bonjour• SNMP v1, v2c, v3

Security

• Administrator and user group protection • HTTP and RTSP authentication

System Requirements for Web Interface

• Operating System: Microsoft Windows 8/7/Vista/XP or Mac with OS X 10.6 or higher
• Browser: Internet Explorer, Firefox, or Safari

Event Management

• Motion detection
• Sound detection
• Event notification and uploading of snapshots/video clips via e-mail or FTP
• Supports multiple SMTP and FTP servers
• Multiple event notifications
• Multiple recording methods for easy backup

Remote Management

• Take snapshots/video clips and save to local hard drive via web browser
• Configuration accessible via web browser

Mobile Support

• mydlink Lite and mydlink+ mobile apps for iOS and Android mobile devices

D-ViewCam™ Software Functions

• Supports all management functions provided in web interface
• Viewing of up to 32 cameras on one screen
• Remote management/control of up to 32 cameras
• Scheduled motion triggered, or manual recording options

D-ViewCam™ System Requirements

• Operating System: Microsoft Windows 8/7/Vista/XP
• Web Browser: Internet Explorer 7 or higher
• Protocol: Standard TCP/IP

Power

• 5 V DC, 1.2 A through external power adapter or PoE connection
• External Power Adapter Input: 100 to 240 V AC, 50/60 Hz

Power Consumption

• 4.6 watts max. ± 5% (using a 5 V DC adapter) • 6.1 watts max. ± 5% (using PoE)

Temperature

• Operating: -25 to 45 °C (-13 to 113 °F) • Storage: -20 to 70 ?C (-4 to 158 ?F)

Humidity

• Operating: 20 to 80% non-condensing • Storage: 5% to 95% non-condensing

Weight

• 280 grams (9.88 ounces) ± 5%

Certifications

• CE • CE LVD • IP65 • FCC • C-Tick • IK-10 Certified
