SPECIFICATION

SYSTEM REQUIREMENTS

• Cable or DSL modem with Ethernet port
• Computer with:
• Windows XP SP2 or Windows 2000 SP4 or Mac OS X
• (v10.4/v10.3) or Linux-based Operating System
• An installed Ethernet adapter
• Internet Explorer 6 or Firefox 2.0 or higher

STANDARDS

• IE 802.11b
• IE 802.11g
• IE 802.11n (draft 2.0)
• IE 802.3
• IE 802.3u

WIRELES FREQUENCY RANGE

• 2.4 GHz to 2.4835 GHz

ANTENNAS

• 2 Fixed 5 dbi External Antennas

SECURITY

• WEP 64/128-Bit Data Encryption
• Wi-Fi Protected Access (WPA/WPA2)
• WPS™ (PBC/PIN)

ADVANCED FEATURES

• UPnP™ Support
• WDS
• WDS + AP
• IP/MAC Binding
• Traffic Control

ADVANCED FIREWAL FEATURES

• Network Address Translation (NAT )
• Stateful Packet Inspection (SPI)
• MAC Address Filtering
• URL Filtering

DEVICE MANAGEMENT

• Web UI

DIAGNOSTIC LEDS

• Power
• Internet
• WLAN
• LAN

POWER INPUT

• 12 V DC/ 2 A Through External Power Adapter

DIMENSIONS (L X W X H)

• 113.2 x 147.5 x 31.5 mm(4.4 x 5.8 x 1.2 inches)

WEIGHT

• 246 grams (0.5 lb)

OPERATI NG TEMPERATURE

• 0° to 40° C (32° to 104° F)

OPERATI NG HUMIDITY

• 0% - 90% non-condensing

CERTIFICATIONS

• CE
• WPS
• CCC
