SPECIFICATION

Camera Hardware Profile
• 1/4” Megapixel CMOS sensor
• Built-in Infrared-Cut Removable (ICR) Filter module
• 5 meter IR illumination distance
• Minimum illumination: 0 lux with IR LED on
• Built-in microphone and speaker
• Digital zoom
• Pan range: -170° to 170°
• Tilt range: -25° to 95°
• Focal length: 3.3 mm
• Minimum object distance: 200 mm
• Aperture: F2.2
• Angle of view:
• (H) 70.4°
• (V) 43°
• (D) 84.6°
Connectivity
• 802.11 b/g/n wireless with WEP/WPA/WPA2 support
• Operates over the 2.4 GHz frequency band
• Single-band 1T1R mode supports a maximum data rate of 72.2 Mbps (PHY rate) using 20 MHz bandwidth
External Device Interfaces
• microSDHC card slot 3
• Reset button
• Direct button
• Power port (Micro-USB)
LEDs • PWR LED: Link/Activity/Power • Cloud LED: Cloud/Direct Mode
Image Features • Configurable image size • Time stamp overlay
Video Compression • H.264 format video compression • JPEG for still images
Video Resolutions • 1280 x 720 up to 30 fps • 640 x 352 up to 15 fps
Audio Support
• AAC
• ADPCM
• 5 built-in lullabies

Baby Monitoring Features • Sound detection with adjustable sensitivity
• Motion detection with adjustable sensitivity
• Records snapshots and video to microSD when motion or sound is detected
• Temperature detection with configurable alert range
• Sends notifications when sound or motion is detected
• 2-way audio lets you listen and respond to your child
Mobile App
• mydlink Baby Camera Monitor app available on the App Store® and Google Play™
• Compatible with iPhone, iPad, or Android smartphones or tablets

Network Protocols
• IPv4
• ARP
• TCP/IP
• UDP
• ICMP
• DHCP client
• HTTP
• HTTPS (for configuration)
• UPnP port forwarding
• RTP/RTSP/RTCP
Security
• Administrator protection
• Password authentication
• HTTP authentication
Dimensions (L x W x H) • 114.16 x 109.16 x 131.3 mm (4.5 x 4.3 x 5.2 inches)
Weight • 396 g (14 oz) ± 5%
Power Input • 5 V DC / 2 A, 50/60 Hz power adapter • Can be powered by an external USB battery with at least 2 A output
Power Consumption • 7.5 watts max. ± 5%
Temperature • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -20 to 70 °C (-4 to 158 °F)
Humidity • Operating: 20% to 80% non-condensing • Storage: 5% to 95% non-condensing
Certifications
• CE
• CE LVD
• FCC Class B
• ICES
• C-Tick
